Durable Vibration Test Table For Long Lasting And High Performance Testing

Name: Durable Vibration Test Table For Long Lasting And High Performance Testing
Brand: Jianqiao
Price: 1 USD

Best Durable Vibration Test Table For Long Lasting And High Performance Testing wholesale

Brand Name : Jianqiao

Model Number : JQA-031-150

Certification : CE

Place of Origin : China

MOQ : 1

Supply Ability : 300 sets

Packaging Details : Wooden case

Frequency : 2000Hz

Sine force : 30kN /3000kg/6740lbf

Random force : 30kN /3000kg/6740lbf

Shock force : 12kN /1200kg/2696lbf

Channel : 2/4/8/16

Maximum acceleration : 100g

Maximum displacement : 100mm (4"）/76mm (3")/51mm (2")

Maximum load : 500KG

moving parts mass : 30KG

Armature diameter : 150mm

Contact Now

Durable Vibration Test Table for Long-Lasting and High-Performance Testing

Durable Vibration Test Table For Long Lasting And High Performance Testing

Shaker Model	JQA-302-340/JQA-303-340
Frequency Range (Hz)	5~2800
Rated sinusoidal force (KN)	30
Shock force (KN)	60
Max. acceleration (m/s²)	980
Max. speed (m/s)	2
Max. displacement (mmp-p)	51/76/100mm
Max. load (kg)	500
Vibration isolation frequency(Hz)	2.5
Shaking table type	JQ-30
Moving parts weight (kg)	32
Armature diameter (φmm)	340
Allowable eccentric moment (N x m)	490
Outer dimension (W·H·D)(mm)	12001120900
Shaker weight (kg)	2450
Power amplifier model	PA-30
Max. output power(KVA)	30
Amplifier Size (W·H·D)	5501750850
Power amplifier Weight (kg)	450
Power Amplifier working model	Switch
System power consumption (KVA)	45
Cooling method	Forced air cooling
Fan model	FJ-3000
Rated flow (m³/min)	40
Rated wind pressure (kPa)	3.5/8.8
Fan power (KW)	7.5

Durable Vibration Test Table For Long Lasting And High Performance Testing

Guangdong Jianqiao Testing Equipment Co.,Ltd is a large scale professional manufacturer specializing in R&D ,production and sales of vibration test system,environmental test chamber and battery testing equipment.With the advantage in Technicians in R&D department,professional production and sales teamand perfect after-service department.and several ,senior R&D Engineer haired across the country .Our marketing network covers major large and medium-sized cities among the country. In the past 20 years, Jianqiao provide high quality products and one -stop solutions for dozens of top 100 enterprises and 11289 end users.

The company manufactures all kinds of vibration and environmental testing equipment in strict accordingwith ISO9001 and products meet the standard of ISO, ASTM , DIN ,EN , BS , UL , JIS , GB/T , GJB,JIS,ANIS,UL,IEC etc. and other domestic and international standards .Our products are widely used in New energy vehicles, aerospace, - shipping, electronics industry and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields.

Durable Vibration Test Table For Long Lasting And High Performance Testing
